1、External battery bracket for 17A or bigger battery with dismountable structure.easy for package and transportation.
2、Three-in-one Digital Indicator can indicate voltage,frequency and working time.
3、with AVR to automatically regulate voltage
|
|
KYQF6.5 |
|
Rated voltage |
230V |
|
Rated current |
27A |
|
Max. output |
6.5KW |
|
Rated output |
6.2KW |
|
Rated frequency |
50HZ |
|
Generator operating system |
Brush,single phase |
|
Voltage regulate |
Automatic voltage regulation |
|
Socket style |
European-style |
|
Fuel tank capacity |
25L |
|
Fuel consumption |
≤374/kw.h |
|
Starting system |
Recoil start |
|
Engine model |
190F/190FD |
|
Displacement |
420ml |
|
Rated output |
7.5kw/3600rpm |
|
Max. torque |
23.5N.m/2600rpm |
|
Engine type |
Single-cylinder OHV25°inclined,four-stroke, forced,air-cooled |
|
Net/gross weight |
81.5/85kg |
|
Dimensions |
690*525*555mm |
|
Qty/20'GP/40'HQ |
136/292set |
