1、External battery bracket for 17A or bigger battery with dismountable structure.easy for package and transportation.
2、Three-in-one Digital Indicator can indicate voltage,frequency and working time.
3、with AVR to automatically regulate voltage
|
|
KYQF2.8 |
|
Rated voltage |
230V |
|
Rated current |
12.2A |
|
Max. output |
3.0KW |
|
Rated output |
2.8KW |
|
Rated frequency |
50HZ |
|
Generator operating system |
Brush,single phase |
|
Voltage regulate |
Automatic voltage regulation |
|
Socket style |
European-style |
|
Fuel tank capacity |
15L |
|
Fuel consumption |
≤395/kw.h |
|
Starting system |
Recoil start |
|
Engine model |
170F |
|
Displacement |
212ml |
|
Rated output |
4.2kw/3600rpm |
|
Max. torque |
11.5N.m/2500rpm |
|
Engine type |
Single-cylinder OHV25°inclined,four-stroke, forced,air-cooled |
|
Net/gross weight |
45/47kg |
|
Dimensions |
600*445*455mm |
|
Qty/20'GP/40'HQ |
240/485set |
