1、Cast iron transmission box with high-strength and durable performance
2、High-strength and high wear-resistant specialized tiller chain with 3 times longer working life
3、Adjustable handlebar to meet different requirements
4、Optional Oil-bath air filter better dust filtration effect to lengthen the working life of engine
5、Grass cutter can be attached by adding 3 pulleys and connecting shaft
|
|
KY95FQ |
|
Gear shifting |
R:1 F:1,2 |
|
Transmission |
Gear + chain |
|
Clutch |
Belt tension clutch |
|
Tilling depth |
≥100mm |
|
Tilling width |
950mm |
|
Wheels |
3.50-6/4.00-8 |
|
Blades |
3 pieces, 4 groups dry-land blades |
|
Engine model |
170F |
|
Rated output |
4.2/3600kW/rpm |
|
Displacement |
212ml |
|
Fuel consumption |
≤395g/(kW.h) |
|
Starting mode |
Recoil start |
|
Package mode |
Carton + hob |
|
Dimensions |
670 x 430 x 815mm |
|
Net/gross weight |
75.5/86kg |
|
Qty/20'GP/40'HQ |
84/264 set |
